Heavy duty cable carriers for most applications

The E4.1 e-chain® system combines all the benefits of its three predecessors in the E4 range. E4.1 cable carriers offer greater stability with the same or smaller dimensions while almost all the accessories and mounting brackets are the same. With igus® E4.1 cable carriers, the service life of your application can be increased and costs significantly reduced.

Contact an expert

Benefits:

Smooth, cable friendly interior surfaces
Low noise operation thanks to integrated "brake" on the radial stop dogs
Sound dampers available as an additional noise-reducing feature
Suitable for a wide range of applications
Numerous interior separation options available
Widths up to 2000 mm through extension links
Can open on both sides
Max. travel distance: Over 656 ft

Industries:
Port and Terminal Cranes, Indoor/EOT Cranes, Composting systems, Sewage treatment plants, Machine tools, General mechanical engineering, Materials-handling Technology, Construction machinery, Wood working & Robotics

Download the E4.1 Selection Guide

e-chain® with crossbars every link, openable from both sides - robust version

Series E4.21

inner height hi: 21mm
inner width Bi: 30 - 120mm
bend radius R: 38 - 200mm
pitch: 30.5mm

e-chain®, crossbars every link

Series E4.28

inner height hi: 28mm
inner width Bi: 40 - 300mm
bend radius R: 55 - 250mm
pitch: 46mm

e-chain®, crossbars every link

Series E4.32

inner height hi: 32mm
inner width Bi: 50 - 400mm
bend radius R: 63 - 300mm
pitch: 56mm

e-chain®, crossbars every link

Series E4.42

inner height hi: 42mm
inner width Bi: 50 - 400mm
bend radius R: 75 - 350mm
pitch: 67mm

e-chain®, crossbars every link

Series E4.56

inner height hi: 56mm
inner width Bi: 50 - 600mm
bend radius R: 135 - 500mm
pitch: 91mm

e-chain®, crossbars every link

Series E4.80

inner height hi: 80mm
inner width Bi: 50 - 600mm
bend radius R: 150 - 1000mm
pitch: 111mm

e-chain®, crossbars every link

Series E4.112

inner height hi: 112mm
inner width Bi: 50 - 600mm
bend radius R: 200 - 1000mm
pitch: 143mm

e-chain®, crossbars every link

Series E4.162

inner height hi: 162mm
inner width Bi: 200 - 600mm
bend radius R: 250 - 1000mm
pitch: 200mm

e-chain®, crossbars every link

Series 800

inner height hi: 200mm
inner width Bi: 200 - 600mm
bend radius R: 325 - 1000mm
pitch: 250mm

e-chain®, crossbars every link

Series 840

inner height hi: 204mm
inner width Bi: 100 - 563mm
bend radius R: 325 - 1000mm
pitch: 250mm

e-chain®, crossbars every link

Series E4.350

inner height hi: 350mm
inner width Bi: 400 - 800mm
bend radius R: 500 - 1000mm
pitch: 470mm

e-chain®, crossbars every link

e-chain® with crossbars every 2nd link, openable from both sides - standard version

Series H4.32

inner height hi: 32mm
inner width Bi: 50 - 400mm
bend radius R: 63 - 300mm
pitch: 56mm

e-chain®, with crossbars every 2nd link

Series H4.42

inner height hi: 42mm
inner width Bi: 50 - 400mm
bend radius R: 75 - 350mm
pitch: 67mm

e-chain®, with crossbars every 2nd link

Series H4.56

inner height hi: 56mm
inner width Bi: 50 - 600mm
bend radius R: 135 - 500mm
pitch: 91mm

e-chain®, with crossbars every 2nd link

Series H4.80

inner height hi: 80mm
inner width Bi: 50 - 600mm
bend radius R: 150 - 1000mm
pitch: 111mm

e-chain®, with crossbars every 2nd link

e-tube, openable from both sides, pivoting lid - protection against chips and dirt

Series R4.28

inner height hi: 28mm
inner width Bi: 50 - 300mm
bend radius R: 63 - 250mm
pitch: 46mm

e-tube, lid pivoting

Series R4.32

inner height hi: 32mm
inner width Bi: 50 - 300mm
bend radius R: 125 - 300mm
pitch: 56mm

e-tube, lid pivoting

Series R4.42

inner height hi: 42mm
inner width Bi: 50 - 300mm
bend radius R: 125 - 350mm
pitch: 67mm

e-tube, lid pivoting

Series R4.56

inner height hi: 56mm
inner width Bi: 75 - 462mm
bend radius R: 150 - 500mm
pitch: 91mm

e-tube, lid pivoting

Series R4.80

inner height hi: 80mm
inner width Bi: 150 - 460mm
bend radius R: 200 - 1000mm
pitch: 111mm

e-tube, lid pivoting

Series R4.112

inner height hi: 112mm
inner width Bi: 200 - 400mm
bend radius R: 250 - 1000mm
pitch: 143mm

e-tube, lid pivoting

E4Q e-chains® for tool-free assembly

E4Q is the newest generation of e-chain®. Based on the e-chain® standard E4.1, the new series offers a long service life, a high level of modularity and new technology within the crossbars which facilitate tool-free assembly.

The crossbars feature an easy to open mechanism which does not require any tools. Simply, lift the latch with your thumb on each end to remove and snap it shut to attach. This innovative new solution cuts the assembly time by up to 40% compared to the standard E4.1 e-chain®.
